Many cavalier King Charles spaniels suffer from a painful genetic disorder called dry eye syndrome (keratitis sicca or keratoconjunctivitis sicca -- KCS), according to the American College of Veterinary Ophthalmologists (ACVO). Research studies have shown that cavaliers are more pre-disposed to KCS -- at a relative risk of 11.5% -- than any other breed.
Dry eye is an inflammation of the cornea and conjunctiva due to an inability to produce watery tears. It also is referred to as tear film deficiency and aqueous tear deficiency. It cannot be cured in cavaliers.
Dry eye prevents the cavalier's eyes from being properly moistened, resulting in chronically dry, burning eyes, and scarring and painful ulceration of the cornea which may lead to decreased vision. The disorder requires frequent medication every day.
A rarer but far more severe form of dry eye syndrome in some cavalier King Charles spaniel puppies is a combination of dry eye and a congenital skin condition called "curly coat" or "rough coat" syndrome (ichthyosis keratoconjunctivitis sicca). See Curly Coat for details.
All CKCSs should be examined at least annually by a board certified veterinary ophthalmologist. They are listed on this webpage of the website of the American College of Veterinary Ophthalmologists (ACVO).
In the cavalier King Charles spaniel, the most common cause of dry eye syndrome is an immune-mediated destruction of the tear glands. Initial symptoms include chronic redness of the eye, chronic thick, yellow-green discharge, especially in the morning, and the development of a film over the cornea. (See photo above.)
Tear production in the dog's eyes is tested by placing a small strip of treated paper beneath the lower eyelid. This is called the Schirmer tear test.
The Schirmer tear test (STT) measures tear production and reflex tear response and is used to diagnose dry eye, as well as other ophthalmic conditions. The STT package contains two sterile test strips, one for each eye. (See photo at right.) The tip of the strip is inserted between the lower eyelid and cornea and left in place for one minute, removed, and read immediately using the scale on the strip.
A normal value for dogs is ≥15 mm wetting/minute. A 10 to 15 mm wetting/minute result is considered borderline for dry eye, and treatment should be started if the dog shows signs of dry eye. Results <10 mm wetting/ minute is positive for dry eye.
In a September 2017 article, Drs. David Williams and Heather Hewitt reported observing differing patterns of dried drops of tears from control dogs and those affected with dry eye. Patterns from the tears of normal dogs were "strikingly beautiful" ferning covering the entire face of the drops (at left). In dogs, including cavaliers, with progressively severe keratoconjunctivitis sicca (KCS), the dried crystals were smaller and less fern-like (at right). He found that all eyes with KCS had abnormal ferning patterns while 39 out of the 50 normal dogs (78%) had so-called ‘normal’ ferning patterns. The mean Schirmer tear test type 1 (STT) for dogs showing ‘normal’ ferning patterns was 20.6mm/min for the left eye and 21.3mm/min for the right eye. STT values for eyes with ‘abnormal’ ferning patterns were 10.9mm/min and 12.4mm/min, these differing from the normal eyes with STT above 15mm/min significantly. He concluded that the findings suggest that tear ferning could be a valuable technique for assessment of the tear film in dogs with KCS.
In a December 2017 article, Dr. David L. Williams reported on the success of using Rose Bengal stain in the eyes of dogs affected with dry eye. Of the 20 affected dogs in the study, 5 were cavalier King Charles spaniels. He concluded that there was a reasonable association between dye staining of the ocular surface and tear production, although clearly other factors are also important in the genesis of ocular surface damage in dry eye. (Photo at right is of an 8 year old Cavalier King Charles spaniel with STT of 4mm/min and staining both of conjunctiva and cornea together with corneal haze and neovascularisation.)
Early treatment of dry eye is crucial to preventing destruction of the CKCS's cornea. Treatment is aimed at increasing tear production, applying artificial tears, and reducing any bacterial infections, and decreasing inflammation and scarring of the cornea. The dog's eyes must be kept clean and free of discharge. The patient may be treated initially with a topical antibiotic or anti-inflammatory.
-- topical ointments, etc.
Lacrimostimulant medications such as cyclosporin 1% and 2%, cyclosporine ophthalmic emulsion (Restasis) or ointment (Optimmune) and tacrolimus ophthalmic suspension are commonly prescribed daily for life to increase tear production, and artificial tear solutions must be applied frequently each day to eliminate bacteria, rinse the eyes, and remove discharge. Cyclosporin 1% and 2% are available at reduced cost, with veterinarians' prescriptions, through an accredited compounding pharmacy on the Internet, Premier Pharmacy Labs, Inc.
NOTE: In a 2008 study of 25 dogs, including a cavalier, researchers observed that "brachycephalic dogs with a background of chronic keratitis that are treated with nonsteroidal anti-inflammatory drugs [including cyclosporine] are at risk to develop axial corneal SCC [squamous cell carcinoma]. The increase in annual cases of SCC suggests that this phenomenon is a developing problem." See also a 2011 study which concluded, "Chronic inflammatory conditions of the cornea and topical immunosuppressive therapy may be risk factors for developing primary corneal SCC in dogs."
In a 2013 study, Dr. David L. Williams reports developing a gel which does not require as many doses per day as do the liquid medications. The gel is a crosslinked hydrogel based upon a modified, thiolated hyaluronic acid (HA), which he has labelled xCMHA-S. He stated:
"Further, in a preliminary clinical study of dogs with KCS [including 3 CKCSs], the gel significantly reduced the symptoms associated with KCS within two weeks while only being applied twice daily. The reduction of symptoms combined with the low dosing regimen indicates that this gel may lead to both improved patient health and owner compliance in applying the treatment."
See also Dr. Williams' June 2014 article on this product, which has the brand name Remend by Bayer. He states that it "seems to provide a particularly efficacious tear replacement in each canine KCS patient in which we have tried it".
Surgery rarely is a successful option. In severe cases that do not respond to medications, an expensive surgical procedure called a parotid duct transposition may be performed in which a salivary duct is moved from the mouth to the eye. This results in saliva flowing over the eye to keep the eye moist. It is not an ideal treatment for dry eye, because saliva is not the same as tears, and the flow of saliva cannot be as well controlled. The surgery is helpful, however, for those dogs that remain persistently painful and squinty despite trying all forms of medical therapy.
However, in a November 2013 article, a team of Brazilian veterinary ophthalmology surgeons report their success in treating 17 dogs with dry eye by grafting salivary glands from the dogs' lips to their inner eye lids. The dogs' dry eye conditions were immune-mediated and unresponsive to medical treatment.
"We found a significant clinical improvement in cases of moderate to severe KCS, as well as those which were nonresponsive to medical treatment, as evidenced by clinical examination and statistical tests. Transplantation of labial salivary glands showed that lubrication of the ocular surface by salivary secretion is stable and effective. ... This technique is simple, quick and effective, accessible to any veterinary ophthalmologist surgeon and is of great value for moderate and severe cases of dry keratoconjunctivitis not responsive to medications."
The Canine Inherited Disorders Database recommends that dogs affected with dry eye not be bred. Since dry eye is an hereditary disease in cavaliers, breeders also should never breed any CKCS which has parents or grandparents which have had dry eye. Dry eye in any littermates of breeding stock should be taken into consideration.
The Cavalier King Charles Spaniel Club, USA recommends that, prior to breeding any cavalier, the dog have a normal rating from a screening by a board certified veterinary ophthalmologist.
The Canine Health Information Center (CHIC) is a centralized canine health database sponsored by the AKC/Canine Health Foundation (AKC/CHF) and OFA. The CHIC, working with participating parent clubs, provides a resource for breeders and owners of purebred dogs to research and maintain information on the health issues prevalent in specific breeds.
AKC's national breed clubs establish the breed specific testing protocols. Dogs complying with the breed specific testing requirements are issued CHIC numbers. The ACKCSC requires that, to qualify for CHIC certification, cavaliers must have a CERF eye examination, recommending that an initial CERF exam be performed at 8 to 12 weeks, with a follow up exam once the dog reaches 12 months, and annual exams thereafter until age 5 years, and every other year until age 9 years. However, all that is required to qualify for a CHIC certificate is that the breeding stock be examined by a veterinary ophthalmologist. It does not require that the results of the examination show no eye disorders.
Nevertheless, all cavalier breeding stock should be examined by board certified veterinary ophthalmologists at least annually and cleared by the veterinary specialists for dry eye, the closer the examination to the breeding the better.
Ocu-GLO Rx is a nutraceutical containing several natural antioxidants in a combination blend formulated specifically for canine eye health. Many veterinary ophthalmologists recommend this product to maintain healthy eyes. Even if your dog has not been diagnosed with a vision disorder, antioxidants contained in Ocu-GLO Rx are considered helpful in keeping dogs' eyes healthy.
December 2017: Dr. David Williams reports on current concepts of dry eye diagnosis and treatment. In a December 2017 article, Dr. David Williams of the Unversity of Cambridge presents a tidy review of the current concepts of diagnosis and treatment of canine keratoconjunctivitis sicca (KCS) -- dry eye. In this review article, he notably points out his recent research on "tear ferning" (comparing fern-like patterns of dried tear drops from dogs with normal tear production and those with severe KCS) and on staining with the vital dye Rose Bengal. He lists cavalier King Charles spaniels among the handful of breeds genetically inclined to suffer from dry eye. He also reviews current treatment options, including a variety of ointments.
December 2017: Dr. David Williams reports that Rose Bengal staining indicates tear production level of dry-eye cavaliers. In a December 2017 article, UK ophthalmologist Dr. David L. Williams reports on the success of using Rose Bengal stain in the eyes of dogs affected with dry eye (keratoconjunctivitis sicca). Of the 20 affected dogs in the study, 5 were cavalier King Charles spaniels. He concluded that there was a reasonable association between dye staining of the ocular surface and tear production, although clearly other factors are also important in the genesis of ocular surface damage in dry eye. (Photo at right is of an 8 year old Cavalier King Charles spaniel with STT of 4mm/min and staining both of conjunctiva and cornea together with corneal haze and neovascularisation.)
September 2017: Dr. David Williams reports patterns in dried tears differ markedly between dogs with normal eyes and those with dry eye. In a September 2017 article, Drs. David Williams and Heather Hewitt report on discovering differing patterns of dried drops of tears from control dogs and those affected with dry eye. Patterns from the tears of normal dogs were "strikingly beautiful" ferning covering the entire face of the drops (at left). In dogs, including cavaliers, with progressively severe kerato-conjunctivitis sicca (KCS), the dried crystals were smaller and less fern-like (at right). He found that all eyes with KCS had abnormal ferning patterns while 39 out of the 50 normal dogs (78%) had so-called ‘normal’ ferning patterns. The mean Schirmer tear test type 1 (STT) for dogs showing ‘normal’ ferning patterns was 20.6mm/min for the left eye and 21.3mm/min for the right eye. STT values for eyes with ‘abnormal’ ferning patterns were 10.9mm/min and 12.4mm/min, these differing from the normal eyes with STT above 15mm/min significantly. He concluded that the findings suggest that tear ferning could be a valuable technique for assessment of the tear film in dogs with KCS.
June 2016: Brazilian ophthalmology surgeons transplant lip salivary glands to dogs' inner eye lids to cure dry eye. In a November 2013 article, a team of Brazilian veterinary ophthalmology surgeons report their success in treating 17 dogs with dry eye by grafting salivary glands from the dogs' lips to their inner eye lids. The dogs' dry eye conditions were immune-mediated and unresponsive to medical treatment.
"We found a significant clinical improvement in cases of moderate to severe KCS, as well as those which were nonresponsive to medical treatment, as evidenced by clinical examination and statistical tests. Transplantation of labial salivary glands showed that lubrication of the ocular surface by salivary secretion is stable and effective. ... This technique is simple, quick and effective, accessible to any veterinary ophthalmologist surgeon and is of great value for moderate and severe cases of dry keratoconjunctivitis not responsive to medications."
April 2015: VetCompass analysis shows frequent diagnoses of dry eye in cavaliers. In an April 2015 report by UK and Australian veterinarians (Jennifer F Summers, Dan G O’Neill, David B Church, Peter C Thomson, Paul D McGreevy, David C Brodbelt), the veterinary records of 1,875 cavalier King Charles spaniels treated between 2009 and 2013 and on the database of the VetCompass animal health surveillance project, were dissected. Only 75 of the 1,875 cavaliers had a confirmed KC-registration status. They found that dry eye [KCS] was particularly frequent, with a proportion of the unspecified corneal disorders and chronic keratitis cases possibly also due to undiagnosed KCS.
August 2013: Dr. David L. Williams develops a gel for treating dry eye. In a 2013 study, Dr. David L. Williams (at right) of UK's Cambridge University, reports developing a gel which does not require as many doses per day as due the liquid medications. The gel is a crosslinked hydrogel based on a modified, thiolated hyaluronic acid (HA), labelled "xCMHA-S". He stated:
"Further, in a preliminary clinical study of dogs with KCS [including 3 CKCSs, the gel significantly reduced the symptoms associated with KCS within two weeks while only being applied twice daily. The reduction of symptoms combined with the low dosing regimen indicates that this gel may lead to both improved patient health and owner compliance in applying the treatment."
July 2012: OSU seeks dogs with dry eye for cyclosporine study. Ohio State University's vet school is seeking dogs with dry eye for a study of a new formulation of the topical drug cyclosporine. To qualify for enrollment in this study, dogs must have confirmed diagnosis of dry eye and not be currently treated with a cyclosporine-type drug. All study medication will be provided at no cost; all examination charges following study enrollment will be covered by the study.
Initially, a routine complete ophthalmic examination will need to be performed to determine the patient's eligibility. This includes an evaluation of ocular discharge and comfort, menace and pupillary light responses, penlight examination, slitlamp examination, Schirmer Tear Test (STT), determination of the Tear Break-up time, flourescein stain uptake, determination of intraocular pressure and indirect ophthalmoscopy following dilation of the pupils. If deemed eligible, you are required to fill out a questionaire, and your dog will be randomly assigned to a treatment group (the study drug or 1% cyclosporine). Both medications are to be administered every 12 hours for the duration of the study. The veterinarian will be blinded during the course of the study, i.e. will not know which drug your dog is receiving. A routine STT will need to be performed on Day 7 and 14 which can be performed at OSU or at your local referring veterinarian. A 1 month and 2 month recheck will need to be performed at OSU. During these visits you will need to fill out a questionaire, and a routine complete ophthalmic eximation will be performed on your dog. Contact Dr. David Wilkie, email@example.com or Dr. Anne Metzler, firstname.lastname@example.org, or call 614-292-3551 for further information. Click here for their webpage. OSU is offering $500.00 to referral veterinarians, so tell your vet about it!
December 2011: UK researchers find dry eye medications have mixed results. In a 2011 UK study of cavaliers suffering from both dry eye and curly coat syndrome, the researchers found that "lacrimostimulant treatment [e.g., cyclosporin] had no statistically significant effect on Schirmer tear test results, although subjectively, this treatment reduced progression of the keratitis [dry eye]."
April 2011: Animal Health Trust Starts DNA Test for Curly Coat in Cavaliers. On April 18, 2011. Animal Health Trust (AHT) begins offering to cavalier breeders its DNA test to detect the mutations causing dry eye/curly coat syndrome, through the AHT’s online DNA testing webshop. The DNA test is available world-wide. Read more here.
November 2010: DNA Region for Curly Coat Has Been Found. Animal Health Trust (AHT) veterinary geneticist Dr. Tom Lewis announced at the UK Cavalier Club's "Cavalier Health Day" on November 20 that the DNA region for the curly coat syndrome in cavaliers has been located. The AHT is continuing its research, started by the late Dr. Keith C. Barnett, to identify the precise mutations of gene(s) causing curly coat syndrome (ichthyosis keratoconjunctivitis sicca). The Trust's future plan is to offer a DNA test for the mutations to cavalier breeders.
March 2009: Dr. Keith C. Barnett died on March 10, 2009. Read his obituary.
April 2007: Researchers find cavaliers are more likely to acquire ulcerative dry eye. Drs. R. F. Sanchez (England), G. Innocent (Scotland), J. Mould (England), and F. M. Billson (Australia) reported in an April 2007 report that the cavalier King Charles spaniels in their study "showed a more acute disease pattern with a biphasic age distribution at 0 to less than two years of age, and four to less than six and six to less than eight years of age, respectively, with more males affected than females and a significantly higher incidence of ulcerative keratitis in some cases resulting in corneal perforation."
March 2007: UK researchers seek genes causing dry eye and curly coat in cavaliers. The Animal Health Trust (AHT) in the UK is conducting research to try to establish the pattern of inheritance of CKCS puppies born with the combination of both dry eye and curly coat syndrome (ichthyosis keratoconjunctivitis sicca), which appears to be unique to the cavalier as a breed. According to Dr. Keith C. Barnett (left), European specialist in veterinary ophthalmology, who has been studying these conditions for several years, no cases of the two abnormalities occurring together have been recorded in any other breed.
Dr. Barnett and Dr. Cathryn Mellersh, senior canine geneticist at the AHT, are leading a team of AHT colleagues who are researching the DNA of the puppies. Dr. Mellersh reports that twenty-seven candidate genes have been identified and the tests are currently in progress and final results are pending.
Dr. Barnett requests that breeders who have puppies affected with these combined disorders send blood samples and skin tissue samples from the affected puppies, their siblings, and parents to identify the responsible gene. Contact Dr. Barnett at the AHT if you wish to participate in the research project. He may be reached at Animal Health Trust, Lanwades Park, Kentford, Newmarket, CB8 7UU, United Kingdom; telephone: (+44) (0)8700 502424; email: Keith.Barnett@aht.org.uk Blood samples of 3 to 5 ml should be provided in ETDA anti-coagulant tubes. Alternatively, for very young or old donors, cheek swabs may be used. Samples should be marked for the attention of Dr. K. Barnett and sent to: Sarah Gray, The Animal Health Trust, Lanwades Park, Newmarket Suffolk CB8 7UU UK. Please indicate clearly that the samples are Curly Coat affected or related. Dr. Mellersh may be reached at Animal Health Trust, Lanwades Park, Kentford, Newmarket, Suffolk CB8 7UU, United Kingdom; telephone: (+44) (0)1638 750659 ; email: email@example.com
Keratoconjunctivitis sicca in the dog: a review of two hundred cases. Jane Sansom, K.C. Barnett. J.Sm.Anim.Pract. March 1985; 26(3):121-131. Quote: "Two hundred consecutive referred cases of keratoconjunctivitis sicca in the dog were examined over a 9 year period [including cavalier King Charles spaniels]. The clinical signs are described and the cases discussed in sections relating to the aetiology and in particular, the age and sex incidence in the West Highland White Terrier. The suitability of this animal as a model for Sjögrens syndrome in man is discussed."
A new perspective on canine keratoconjunctivitis sicca. Treatment with ophthalmic cyclosporine. Kaswan RL and Salisbury MA. Vet Clin North Am (Small Anim Pract). 1990;20:583-613. Quote: "Canine breeds predisposed to keratoconjunctivitis sicca: Cavalier King Charles spaniel ... relative risk 11.5%."
Ocular Disorders Presumed to be Inherited in Purebred Dogs. ACVO 1999.
Control of Canine Genetic Diseases. Padgett, G.A., Howell Book House 1998, pp. 198-199, 240.
Dry eye and curly coat in the Cavalier King Charles Spaniel. Barnett, KC, Veterinary Ophthalmology 6 (4), 343-350, Dec. 2003.
Guide to Congenital and Heritable Disorders in Dogs. Dodds WJ, Hall S, Inks K, A.V.A.R., Jan 2004, Section II(179).
Breed Predispositions to Disease in Dogs & Cats. Alex Gough, Alison Thomas. 2004; Blackwell Publ. 44-45.
Ophthalmic Disease in Veterinary Medicine. Martin C.L. Manson Publ. 2005.
Congenital keratoconjunctivitis sicca and ichthyosiform dermatosis in the cavalier King Charles spaniel. K. C. Barnett. J.Sm.Anim.Prac. 2006 Sep;47(9):524-8. Quote: "Objectives: To record a previously unreported congenital and hereditary condition affecting the eyes and skin in the cavalier King Charles spaniel. ... In the cavalier King Charles spaniel, the coat abnormality was noted at birth by the breeders as a 'curly coat', with deterioration of the skin signs as the animal became adult."
Canine keratoconjunctivitis sicca: disease trends in a review of 229 cases. R. F Sanchez, G Innocent, J Mould, F. M Billson. J.Sm.Anim.Pract.; April 2007;48(4): 211-217. Quote: "There were 44 breeds in the study, with four breeds, English cocker spaniels, cavalier King Charles spaniels, West Highland white terriers and shih-tzus, making up 58 per cent of the cases. ... In contrast, cavalier King Charles spaniels and shih-tzus showed a more acute disease pattern with a biphasic age distribution at 0 to less than two years of age, and four to less than six and six to less than eight years of age, respectively, with more males affected than females and a significantly higher incidence of ulcerative keratitis in some cases resulting in corneal perforation. ... In the USA, predisposed breeds include cavalier King Charles spaniels (CKCS), English bulldogs, Lhasa apsos, shih-tzus, West Highland white terriers (WHWT), pugs, bloodhounds, American cocker spaniels, Pekingeses, Boston terriers, miniature schnauzers and Samoyeds (Kaswan and Salisbury 1990)."
Dry Eye in Veterinary Ophthalmology. Cameron Whittaker, Robin G. Stanley. 32d WSAVA Conf. August 2007. Quote: "What Causes KCS? The vast majority of KCS cases are caused by the body's own immune system i.e., an autoimmune disease directed against the lacrimal gland. Work done in the early 1980s showed that there was a strong mono-nuclear cell infiltrate of lymphocytes and plasma cells into the lacrimal gland suggesting an autoimmune basis. There also seems to be a strong breed predilection for dry eye. Breeds predisposed include ... Cavalier King Charles Spaniels."
Immunopathogenesis of Keratoconjunctivitis Sicca in the Dog. David L. Williams. Vet Clin Small Anim. March 2008. 38(2):251–268. Quote: "Canine breeds predisposed to keratoconjunctivitis sicca: Cavalier King Charles Spaniel, relative risk 11.5% [highest risk level of all breeds of dogs]."
Corneal squamous cell carcinoma in dogs with a history of chronic keratitis. R. R. Dubielzig, C. S. Schobert and J. Dreyfus. Vet Ophth; 2008;11(6):413–429. Quote: "Purpose: Corneal squamous cell carcinoma (SCC) is a rare tumor in dogs. The COPLOW has seen a recent increase in primary SCC in the axial cornea. We report here on 25 cases. Methods: Twenty-five cases of primary axial corneal SCC were selected from the COPLOW collection which includes more that 6000 neoplastic specimens. ... Results: The number of canine corneal SCC has risen in the past several years from 1 case per year from 1998 to 2004, jumping to 6 cases in 2005, 8 cases in 2006, and 7 cases in 2007. Brachycephalic breeds are overrepresented. The breed distribution included 8 Pugs, 5 Bulldog, 2 Boxers, 2 Greyhound, 2 Shi Tzu, 2 Border Collie, 2 Pekinese, 1 Bassett, 1 Chow, 1 Cocker, and 1 Cavalier King Charles Spaniel. No correlation to sex was found. Out of the 25 cases, 21 showed signs of chronic keratitis prior to developing SCC. In the remaining 4 cases the prior corneal history was unknown. Within the group of 25, 10 cases had been treated with cyclosporine alone, 4 with tacrolimus alone, 5 with both cyclosporine and tacrolimus, and 6 treated with other drugs or unknown. Follow-up information was obtained from 23 cases with a follow-up interval of between 5 days and 31 months (mean: 7.9 months). Three dogs had died for reasons unrelated to the ocular disease. One dog had recurrent disease extending deeply into the cornea. Conclusions: Brachycephalic dogs with a background of chronic keratitis that are treated with nonsteroidal antiinflammatory drugs are at risk to develop axial corneal SCC. The increase in annual cases of SCC suggests that this phenomenon is a developing problem."
Congenital keratoconjunctivitis sicca and ichthyosiform dermatosis (ckcsid) in the Cavalier King Charles Spaniel (CKCS) dog: a candidate gene study. C. Hartley, K. C. Barnett, C. S. Mellersh, L. Pettitt and O. P. Forman. Vet Ophthal (2009) 12(6):379–385. Quote: "Purpose: To identify causative mutation(s) for CKCSID in CKCS dogs using a candidate gene approach. Methods: DNA samples from 21 cases/parents were collected. Canine candidate genes (CCGs) for similar inherited human diseases were chosen. Twenty-eight candidate genes were identified by searching the Pubmed database (http://www.ncbi.nlm.nih.gov/sites/entrez/query.fcgi). Canine orthologs of human candidate genes were identified using the Ensembl orthologue prediction facility (http://www.ensembl.org/index.html). Two microsatellites flanking each candidate gene were selected and primers to amplify each microsatellite were designed using the Whitehead Institute primer design website (http://frodo.wi.mit.edu/cgibin/primer3/primer3_www.cgi). The microsatellites associated with all 28 CCGs were genotyped on a panel of 21 DNA samples from CKCS dogs (13 affected, 8 carriers). Genotyping data was analysed to identify markers homozygous in affected dogs and heterozygous in carriers (homozygosity mapping). Results: None of the microsatellites associated with 25 of the CCGs displayed an association with CKCSID in the 21 DNA samples tested. Three CCGs associated microsatellites were monomorphic across all samples tested. Conclusion: Twenty five CCGs were excluded as cause of CKCSID. Three CCGs could not be excluded from involvement in the inheritance of CKCSID."
Ophthalmic Disease in Veterinary Medicine. Charles L. Martin. Manson Publ. 2009; page 475, table 15.1. Quote: "Presumed Inherited Ocular Diseases: Table 15.1: Breed predisposition to eye disease in dogs: Cavalier King Charles Spaniel: ... Exposure keratopathy/macroblepharon".
Breed Predispositions to Disease in Dogs & Cats (2d Ed.). Alex Gough, Alison Thomas. 2010; Blackwell Publ. 51, 54.
New DNA tests for Cavalier King Charles spaniels. Vet Rec 2011 168(14):370. "NEW DNA tests to detect the mutations causing congenital keratoconjunctivitis sicca and ichthyosiform dermatosis (dry eye and curly coat syndrome) and episodic falling in Cavalier King Charles spaniels will be available from the Animal Health Trust (AHT) later this month. Episodic falling is a neurological condition induced by exercise, excitement or frustration. The dog's muscle tone increases and the animal is unable to relax its muscles, becomes rigid and falls over. Dry eye and curly coat syndrome results in an affected dog producing no tears, so its eyes become sore. The skin becomes flaky and dry, particularly around the feet, which can make standing and walking difficult and painful. The syndrome appears to be unique to Cavalier King Charles spaniels and most dogs diagnosed with it are euthanased. Researchers at the Kennel Club Genetics Centre at the AHT have now identified the mutations responsible for the two conditions. This has allowed the development of the new DNA tests, which will be available from the AHT from April 18. Cathryn Mellersh, head of canine genetics at the AHT, said: To date there has been no long-term effective treatment for either dry eye and curly coat syndrome or episodic falling so the development of the DNA tests is an important breakthrough for breeders and owners of Cavalier King Charles spaniels. As with all inherited disease, it's important that breeders are armed with the facts and that they still continue to use carrier dogs in their breeding programmes. Breeding a carrier with a non-carrier will not produce affected puppies; however, breeding just clear dogs with other clear dogs could reduce the gene pool within the breed and this could lead to other health problems in the future."
Superficial corneal squamous cell carcinoma occurring in dogs with chronic keratitis. Jennifer Dreyfus, Charles S. Schobert, Richard R. Dubielzig. Vet Ophth; May 2011;14(3):161-168. Quote: "Objective: Canine corneal squamous cell carcinoma (SCC) is a rare tumor, with only eight cases previously published in the veterinary literature. The Comparative Ocular Pathology Lab of Wisconsin (COPLOW) has diagnosed 26 spontaneously occurring cases, 23 in the past 4 years [three of which were cavalier King Charles spaniels]. This retrospective study describes age and breed prevalence, concurrent therapy, biologic behavior, tumor size and character, and 6-month survival rates after diagnosis. Results: A search of the COPLOW database identified 26 corneal SCC cases diagnosed from 1978 to 2008. There is a strong breed predilection (77%) in brachycephalic breeds, particularly those prone to keratoconjunctivitis sicca. The mean age was 9.6 years (range 6–14.5 years). Follow-up information >6 months was available for 15 of 26 cases. Recurrence occurred in the same eye in nine cases, seven of which were incompletely excised at the time of first keratectomy. No cases were known to have tumor growth in the contralateral eye and no cases of distant metastases are known. Where drug history is known, 16 of 21 dogs had a history of treatment with topical immunosuppressive therapy (cyclosporine or tacrolimus) at the time of diagnosis. Conclusion: Chronic inflammatory conditions of the cornea and topical immunosuppressive therapy may be risk factors for developing primary corneal SCC in dogs. SCC should be considered in any differential diagnosis of corneal proliferative lesions. Superficial keratectomy with complete excision is recommended, and the metastatic potential appears to be low."
Genetic Connection: A Guide to Health Problems in Purebred Dogs, Second Edition. Lowell Ackerman. July 2011; AAHA Press; pg 168. Quote: "Table 11.5 -- Breeds Most Commonly Affected with Keratoconjunctivitis Sicca (KCS): ... Cavalier King Charles spaniel...."
Keratoconjunctivitis associated with eosinophils in dogs: A retrospective study of 35 cases (2004–2009). G. de Geyera, I. Raymond-Letronb. Pratique Médicale et Chirurgicale de l'Animal de Compagnie. doi:10.1016/j.anicom.2011.09.002. Quote: "The objective of this study is to present the clinical and histopathologic features of dogs with keratoconjunctivitis selected based on eosinophils detected in corneal histopathology. Thirty-five cases were reviewed focusing on breed, history, ophthalmic lesions, results of cytology and intradermal allergy testing for 19 allergens, and response to treatment which included keratectomy, topical antibiotics, and corticosteroids in variable conjunction with cyclosporine. Results are: patients included 18 males and 17 females, 9 months to 12 years of age (mean 6.8 years). Among the 34 pure bred dogs were seven Boxers, five French Bulldogs and four Labrador Retrievers. History was that of uni- or bilateral chronic or recurrent corneal ulcers or chronic keratitis. Lesions most commonly were located in the temporal cornea with vessels extending from the limbus centrally to the mid-periphery to form a dense meshwork of thin vessels with an associated superficial stromal infiltrate and a superficial ulcer and associated corneal edema. Conjunctival inflammation and follicular hyperplasia of the bulbar surface of the third eyelid were a consistent finding. Ocular surface cytology showed a predominance of neutrophils and lymphocytes and infrequently eosinophils. Intradermal allergy testing showed a positive reaction to injected aeroallergens in 23 of 26 tested dogs with house dust mite the most common positive allergen. Corneal histopathology showed a hyperplasic epithelium, a lacking basal membrane in the area of corneal defect, an epitheliostromal clivage, a hyalinized acellular zone on the superficial stroma, and corneal infiltrate with neutrophils, monocytes and variable eosinophils. Treatment was effective in all dogs with complete resolution of the ulcers; variable recurrence was successfully managed by topical corticosteroids. In conclusion, this study indicates that eosinophils may participate to the corneal infiltrate of dogs with keratitis associated or not with chronic or recurrent ulcer. Hypotheses include an allergy."
Congenital keratoconjunctivitis sicca and ichthyosiform dermatosis in 25 Cavalier King Charles spaniel dogs – part I: clinical signs, histopathology, and inheritance. Claudia Hartley, David Donaldson, Ken C. Smith, William Henley, Tom W. Lewis, Sarah Blott, Cathryn Mellersh, Keith C. Barnett. Vet.Opht. 29Dec2011. Quote: "The clinical presentation and progression (over 9 months to 13 years) of congenital keratoconjunctivitis sicca and ichthyosiform dermatosis (CKCSID) in the Cavalier King Charles spaniel dog are described for six new cases and six previously described cases. Cases presented with a congenitally abnormal (rough/curly) coat and signs of KCS from eyelid opening. Persistent scale along the dorsal spine and flanks with a harsh frizzy and alopecic coat was evident in the first few months of life. Ventral abdominal skin was hyperpigmented and hyperkeratinized in adulthood. Footpads were hyperkeratinized from young adulthood with nail growth abnormalities and intermittent sloughing. Long-term follow-up of cases (13/25) is described. Immuno-modulatory/lacrimostimulant treatment had no statistically significant effect on Schirmer tear test results, although subjectively, this treatment reduced progression of the keratitis. Histopathological analysis of samples (skin/footpads/ lacrimal glands/salivary glands) for three new cases was consistent with an ichthyosiform dermatosis, with no pathology of the salivary or lacrimal glands identified histologically. Pedigree analysis suggests the syndrome is inherited by an autosomal recessive mode."
Keratoconjunctivitis Sicca in the dog. Sarah Cooper. UK Companion Animal. Oct. 2012; 17(8):37-42.. Quote: "Dry eye or keratoconjunctivitis sicca is a reduction in the aqueous component of the pre-ocular tear film causing inflammation of the ocular surface. It is an important condition in dogs and diagnosis with a Schirmer Tear Test at an early stage can aid in successful treatment."
Ocular Disorders Presumed to be inherited in purebred dogs. Genetics Committee of the American College of Veterinary Ophthalmologists. Blue Book 6th Ed. 2013. pp. 241-247. Quote: "Cavalier King Charles Spaniel: Disorder: B. Keratoconjunctivitis Sicca (Dry Eye). Inheritance: Not defined."
A Crosslinked HA-Based Hydrogel Ameliorates Dry Eye Symptoms in Dogs. David L. Williams, Brenda K. Mann. Int.J. of Biomaterials. 2013. Quote: "Keratoconjunctivitis sicca, commonly referred to as dry eye or KCS, can affect both humans and dogs. ... With immune-mediated KCS in dogs, there is a predisposition for specific breeds having a higher prevalence. These breeds include English Bulldogs, West Highland White Terriers, Cavalier King Charles Spaniels, American and English Cocker Spaniels, and Pugs, with the prevalence reaching as high as 20% in these breeds. ... The standard of care in treating KCS typically includes daily administration of eye drops to either stimulate tear production or to hydrate and lubricate the corneal surface. Lubricating eye drops are often applied four to six times daily for the life of the patient. In order to reduce this dosing regimen yet still provides sufficient hydration and lubrication, we have developed a crosslinked hydrogel based on a modified, thiolated hyaluronic acid (HA), xCMHA-S. This xCMHA-S gel was found to have different viscosity and rheologic behavior than solutions of noncrosslinked HA. The gel was also able to increase tear breakup time in rabbits, indicating a stabilization of the tear film. Further, in a preliminary clinical study of dogs with KCS [including 3 CKCSs], the gel significantly reduced the symptoms associated with KCS within two weeks while only being applied twice daily. The reduction of symptoms combined with the low dosing regimen indicates that this gel may lead to both improved patient health and owner compliance in applying the treatment."
Labial salivary glands transplantation in the treatment of dry eye in dogs by autograft. Leticia Séra Castanho, Hamilton Moreira, Carmen Austrália Paredes Marcondes Ribas, Antônio Felipe Paulino de Figueiredo Wouk, Manuella Sampaio, Tatiana Giordano. Revista Brasileira de Oftalmologia. November 2013. Quote: Objective: To evaluate the clinical effects of lips salivary gland secretion as ocular lubricant for dry eye relief in mild cases, severe and refractory to medical treatment, through the transposition technique of salivary glands autograft to the conjunctival fornix. Methods: Seventeen dogs exhibiting autoimmune dry eye with no satisfactory response to clinical treatment were selected. Lacrimal Schirmer Test and Tear Film break-up time (BUT) preoperative tests were performed to estimate the quantity and the quality of produced tear. Animals were submitted to complete ophthalmic exams routine preoperative, each 15 days for two months and then each 30 days for more two months after surgery, totalizing six returns. Photos were taken before and after surgical procedure for photo archive. Photoshop software was utilized for corneal neovascular evaluation. Results: Mucopurulent secretion, conjunctival hyperemia and blepharospasm diminished in all cases, as well as occurred stabilization of pre existent damages with important reduction of corneal neovascularization. The transposition resulted on break-up time tests improvement but no significant changes on Schirmer tests. Conclusion: This technique is simple, quick and effective, accessible to any veterinary ophthalmologist surgeon and is of great value for moderate and severe cases of dry keratoconjunctivitis not responsive to medications.
Efficacy of a crosslinked hyaluronic acid-based hydrogel as a tear film supplement: a masked controlled study. Williams DL, Mann BK. PLoS One. June 2014;9(6):e99766. Quote: Keratoconjunctivitis sicca (KCS), or dry eye, is a significant medical problem in both humans and dogs. Treating KCS often requires the daily application of more than one type of eye drop in order to both stimulate tear prodcution and provide a tear supplement to increase hydration and lubrication. A previous study demonstrated the potential for a crosslinked hyaluronic acid-based hydrogel (xCMHA-S) to reduce the clinical signs associated with KCS in dogs while using a reduced dosing regimen of only twice-daily administration. The present study extended those results by comparing the use of the xCMHA-S to a standard HA-containing tear supplement in a masked, randomized clinical study in dogs with a clinical diagnosis of KCS [including two cavalier King Charles spaniels]. The xCMHA-S was found to significantly improve ocular surface health (conjunctival hyperaemia, ocular irritation, and ocular discharge) to a greater degree than the alternative tear supplement (P = 0.0003). Further, owners reported the xCMHA-S treatment as being more highly effective than the alternative tear supplement (P = 0.0024). These results further demonstrate the efficacy of the xCMHA-S in reducing the clinical signs associated with KCS, thereby improving patient health and owner happiness.
Diagnosis & Treatment of Keratoconjunctivitis Sicca in Dogs. Lori J. Best, Diane V.H. Hendrix, Daniel A. Ward. Today’s Veterinary Practice. July 2014;16-22. Quote: "Many breeds are predisposed to primary KCS, including, but not limited to, the American cocker spaniel, cavalier King Charles spaniel, West Highland white terrier, and brachycephalic breeds (eg, English bulldog)."
Advances in treating ocular issues. Christine Heinrich. Vet. Times. November 24, 2014:8-12. Quote: "Canine dry eye is a painful and blinding disease, which, unfortunately, is not usually successfully managed with only the use of tear replacements – even if the client has the time and inclination to comply with complex treatment schedules. In the past, it must have been disheartening – even with frequent applications of tear replacements – for colleagues to watch patients with severe dry eye continuing to suffer from excessive amounts of tenacious ocular discharge, progressive corneal pigmentation, vision loss and, at times, devastating corneal ulceration. ... Having started my career in ophthalmology as an intern in 1995, I‘ve never had to manage dry eye patients without the benefit of this drug. The ability of Optimmune to restore tear production and resolve chronic keratitis and pigmentation can be astonishing and, in many patients, normal ocular surface health can be restored with ongoing use of the drug (Figures 5a to 5c [of a cavalier King Charles spaniel at right. Top: 5a: ). Initially, most vets would have formulated their own ciclosporin eye drops in oil, until Optimmune was launched in the mid-1990s as the licensed drug to treat immune-mediated canine dry eye. It is often criticised as a relatively expensive drug that is required life-long to maintain tear production in dry eye patients. The use of alternative, less costly tear replacements might, therefore, be tempting to the vet and owner; however, even in initially mild cases of dry eye, this is, in my view, a false economy, as without the use of immune-modulators, the destruction of the tear glands will progress, eventually resulting in a blind eye at risk of corneal ulceration. Finally, eyes with advanced KCS and Schirmer tear tests (STT) of 0mm to 2mm of wetting have a much-reduced chance to respond positively to the use of Optimmune than those diagnosed and treated earlier in the course of the disease, when STT readings still exceed 2mm of wetting. Careful client education is, therefore, crucial in ensuring compliance with the ongoing use of the drug and efficient dry eye control. To date, it remains the mainstay in the management of immunemediated canine KCS and only few refractory patients require the use of more concentrated formulations of ciclosporin or of more potent topical immunomodulators, such as tacrolimus. However, veterinary licensed preparations of the latter are not yet available and their use has to follow the cascade system."
Prevalence of disorders recorded in Cavalier King Charles Spaniels attending primary-care veterinary practices in England. Jennifer F Summers, Dan G O’Neill, David B Church, Peter C Thomson, Paul D McGreevy, David C Brodbelt. Canine Genetics and Epidemiology. April 2015;2:4. Quote: "This study used large volumes of health data from UK primary-care practices participating in the VetCompass animal health surveillance project to evaluate in detail the disorders diagnosed in a random selection of over 50% of dogs recorded as Cavalier King Charles Spaniels (CKCSs). Confirmation of breed using available microchip and Kennel Club (KC) registration data was attempted. Results: In total, 3624 dogs were recorded as CKCSs within the VetCompass database of which 143 (3.9%) were confirmed as KC-registered via microchip identification linkage of VetCompass to the KC database. ... Microchip data were available in 1692 (46.7%) of the 3624 identified CKCSs. It was possible to crosslink microchip data with KC-registration details in 143 of these dogs; this represented 8.5% of all identified CKCSs with microchip data, and 3.9% of all identified CKCSs. The remaining 3481 dogs were classified as of unknown KC-registration status. The 52% randomly selected sample of all identified CKCSs totalled 1875 dogs: 1800 with unknown and 75 with confirmed KC-registration status. These 1875 dogs were seen at 109 individual clinics during the study period, including 90 (83%) Medivet and 19 (17%) Vets4Pets sites located from north-east to southern England. ...1875 dogs (75 KC registered and 1800 of unknown KC status, 52% of both groups) were randomly sampled for detailed clinical review. Clinical data associated with veterinary care were recorded in 1749 (93.3%) of these dogs. ... Median ages at first and last consultation were 4.0 and 5.25 years, respectively (ranges one month - 17.2 years for both age measures). The most frequent coat colours were Blenheim (44.3%) and tri-colour (30.8%) (Table 1). Of the 1521 dogs with more than one clinical data entry, median time contributed to the study was 1.3 years (range 1 day to 3.6 years). ... Ocular disorders, and particularly corneal diseases, were frequently recorded in study dogs. KCS [dry eye] was particularly frequent, with a proportion of the unspecified corneal disorders (and chronic keratitis cases) possibly also due to undiagnosed KCS. Studies suggest an autosomal recessive mode of inheritance CKCSID in the CKCS. In addition, the typical CKCS skull morphology (with large eyes and shallow eye sockets) may also pre-dispose the breed to corneal damage, exposure keratitis, conjunctival injury and subsequent irritation. Cataracts were recorded relatively frequently in study CKCSs and an inherited basis has been suggested for certain early onset cataracts in the breed. However, the current study could not differentiate between inherited, early forms and age-related degenerative cataracts. DNA screening tests (e.g. CKCSID) and British Veterinary Association (BVA)/KC health schemes (e.g., multifocal retinal dysplasia and hereditary cataract) offer opportunities to reduce population levels of certain inherited conditions through selective breeding. However, the current study indicates that eye disorders remain an important challenge for those concerned with improving the health and welfare of CKCSs. ... Further work This work highlights the value of veterinary practice based breed-specific epidemiological studies to provide targeted and evidence-based health policies. Further studies using electronic patient records in other breeds could highlight their potential disease predispositions."
Canine Keratoconjunctivitis Sicca. Alison Clode. Clinician's Brief. December2015;81-85. Quote: "Predisposed breeds for presumptive immune-mediated KCS include: Cavalier King Charles spaniel ... ."
Preliminary results of a prospective study of inter- and intra-user
variability of the Royal Veterinary College corneal clarity score
(RVC-CCS) for use in veterinary practice. Rick F. Sanchez,
Charlotte Dawson, Màrian Matas Riera, Natàlia Escanilla. Vet.
Ophthalmology. July 2016;19(4):313-318. Quote: Objective: To introduce a
new corneal clarity score for use in small animals and describe its
inter- and intra-user variability. Animals studied: Twelve dogs
[including two cavalier King Charles spaniels] and two cats with corneal
abnormalities and five dogs with healthy corneas. Materials and Methods:
Four examiners scored every patient twice and never consecutively,
focusing on the central cornea. The peripheral cornea was scored
separately. The following scoring system was used to describe corneal
-- G0: no fundus reflection is visible on retroillumination (RI) using a head-mounted indirect ophthalmoscope.
-- G1: a fundus reflection is visible with RI.
-- G2: a 0.1-mm diameter light beam is visible on the anterior surface of the iris and/or lens.
-- G3: gross fundic features are visible when viewed with indirect ophthalmoscopy (IO) using a head-mounted indirect ophthalmoscope and a hand-held 30D lens, although fine details are not clear. (Image at below right is of Cavalier King Charles Spaniel with keratoconjunctivitis sicca and a CLCT OS. The axial cornea of this eye was assigned a G3 because indirect ophthalmoscopy was possible. Gross details of the fundus were visible although the finer details of the fundus were not.)
-- G4: fine details of the fundic features are clearly visible with IO.
The minimum grades given were analyzed for inter- and intra-user variability with kappa analysis. Results: Intra- and interuser variability of the central corneal clarity ranged from 0.78 to 0.96, showing substantial to almost perfect reproducibility, and from 0.66 to 0.91, showing substantial to almost perfect reliability, respectively. Intra- and interuser variability of the peripheral cornea ranged from 0.83 to 0.95, showing almost perfect agreement, and from 0.53 to 0.91, showing moderate to almost perfect agreement. Conclusions: The RVC-CCS is well suited to assess and monitor central corneal clarity in small animals and to compare outcomes between studies and different surgeons.
Dry Eye in Dogs: When Good Glands Go Bad. Shelby Reinstein. Vet. Team Brief. February 2017. Quote: Dry eye, or keratoconjunctivitis sicca (KCS), is a common condition in dogs characterized by decreased tear production that most often results from idiopathic lacrimal gland inflammation with secondary glandular atrophy. Neurogenic KCS is caused by loss of parasympathetic innervation to the lacrimal gland and is less common than immune-mediated KCS. Neurogenic KCS occurs secondary to chronic otitis, peripheral neuropathies, idiopathic disease, and primary neurologic disease. Decreased tear production results in corneal and conjunctival cellular hypoxia, debris accumulation, and bacterial overgrowth, causing inflammation of the ocular surface. Clinical signs include conjunctival hyperemia, squinting, and thick, sticky discharge. ... KCS should be suspected in all patients with clinical signs, especially in those with breed predisposition, including Cavalier King Charles spaniel, cocker spaniel, English bulldog, pug, shih tzu, West Highland white terrier, and Lhasa apso.
Tear ferning in normal dogs and dogs with keratoconjunctivitis sicca. David Williams, Heather Hewitt. Open Vet. J. September 2017;7(3). Quote: This study evaluates tear ferning as an ancillary technique for the evaluation of the canine tear film in normal eyes and eyes affected by keratoconjunctivitis sicca (KCS). Thirty dogs with KCS [including two cavalier King Charles spaniels] and 50 control dogs with normal tear film were evaluated with a full ophthalmoscopic examination and a Schirmer tear test type 1 (STT) determined before tear samples were obtained from the medial canthus with a microhaematocrit capillary tube. 10ul of tear was placed on a microscope slide and the time to first formation of a fern of crystallised tear solute was determined. The appearance of the ferning pattern was graded and correlated with the STT value. All eyes with KCS had abnormal ferning patterns while 39 out of the 50 normal dogs (78%) had so-called ‘normal’ ferning patterns. The mean STT for dogs showing ‘normal’ ferning patterns was 20.6mm/min for the left eye and 21.3mm/min for the right eye. STT values for eyes with ‘abnormal’ ferning patterns were 10.9mm/min and 12.4mm/min, these differing from the normal eyes with STT above 15mm/min significantly. These findings suggest that tear ferning could be a valuable technique for assessment of the tear film in dogs with KCS.
Measurement of tear osmolarity in the canine eye: a new diagnostic tool for canine keratoconjunctivitis sicca? Williams DL, Buckingham A. Research & Reviews: J. Vet. Sci. December 2017;3(2):8-12. Quote: In this study the osmometer was compared with the Schirmer Tear Test I (STT) in 100 dogs from the patient population at the Queen’s Veterinary School hospital, University of Cambridge and a UK animal rehoming facility. 153 eyes were ophthalmoscopically normal and 47 had varying degrees of keratoconjunctivitis sicca (KCS) as determined by STT values below 15mm/min. [including 2 cavalier King Charles spaniels]. ... Corneal ulceration is a frequent sequela, particularly in exophthalmic breeds, such as the Pug or Cavalier King Charles Spaniel, where an imperfect lid closure may exacerbate the problem. ... Animals underwent a full ophthalmic examination and then were sampled using the TearLab device to measure tear osmolarity followed by a standard Schirmer tear test I. Tear osmolality in eyes with normal tear production was compared to that in eyes with KCS using the Student’s T test. Correlation between STT and osmolarity data was investigated using the Pearson rank correlation coefficient. Tear osmolality was significantly higher in eyes with KCS (350 ± 27 mOsm) than in normal eyes (339 ± 23 mOsm) this difference significant at p<0.02. As high tear omolarity is considered to be a key factor in the pathogenesis of ocular surface damage in eyes with aqueous tear film deficiency in human patients, measuring tear film osmolarity in dogs with suspected KCS may be an important diagnostic step in these animals.
Ocular surface Rose Bengal staining in normal dogs and dogs with Keratoconjunctivitis Sicca: Preliminary findings. Williams DL, Griffiths A. Insights in Vet. Sci. December 2017;1:42-46. Quote: Dry eye or keratoconjunctivitis sicca, is commonly seen in the dog. Veterinary ophthalmologists diagnose this aqueous tear deficiency using the Schirmer tear test (STT), but this measures tear production and does not indicate ocular surface pathology. The vital dye Rose Bengal is commonly used in the diagnosis of dry eye in human patients but until now has not been reported in veterinary patients. Here we corelate the degree of Rose Bengal staining with the STT value and find a reasonable association between dye staining of the ocular surface and tear production, although clearly other factors are also important in the genesis of ocular surface damage in dry eye. ... The KCS group comprised 20 adult dogs with 36 eyes with STT<15mm/min)) all diagnosed with to uni-ocular or bilateral KCS. Only eyes with KCS were included in the study. The breeds were West Highland White Terriers (6), Cavalier King Charles Spaniels (4), English Cocker Spaniel (3), American Bulldog (2), Lhasa Apso (2), Pug (1), Mastiff (1) and crossbreed (1). ... Whatever the exact mechanism, the stain evaluates ocular surface pathology rather than merely tear production as does the STT. For that reason the Rose Bengal stain should be a valuable addition to the diagnostic tests used in canine dry eye. (Photo at right is of an 8 year old Cavalier King Charles spaniel with STT of 4mm/min and staining both of conjunctiva and cornea together with corneal haze and neovascularisation.)
Canine Keratoconjunctivitis Sicca: Current Concepts in Diagnosis and Treatment. David Williams. J. Clin. Ophthalmol. & Optom. December 2017;1(1):105. Quote: Keratoconjunctivitis sicca or dry eye is a commonly recognised condition of canine patients in veterinary practice. The majority of cases are seen in a number of pedigree dog breeds from West Highland White terriers, English and American Cocker Spaniels, Cavalier King Charles spaniels, Lhasa Apsos and Shuh Tzus among a number of other breeds. In these animals an immune-mediated destruction of the lacrimal gland appears to be taking place and topical cyclosporine has, for many years, been a valuable treatment option in these animals. Other causes of dry eye are neurological dysfunction and drug-related lacrimotoxicity. In these cases topical cyclosporine is not effective and treatment with tear replacement drops is required. Another option is parotid duct transposition which can give a lasting improvement in ocular surface pathology. Diagnosis of canine dry eye is primarily by use of the Schirmer tear test, in which tear strip wetting of 15-20mm/min is normal and a wetting of less than 10mm/min is characteristic of dry eye. ... Our research has shown an average STT of one thousand dogs with normal eyes of 18.6mm/min but different breeds have significantly different STT values. Interesting a number of breeds classically recognised as predisposed to KCS, namely the West Highland white terrier, the American and English Cocker Spaniel, the Lhasa Apo, Shih Tzu and Cavalier King Charles Spaniel have significantly lower STT results. ... Other diagnostic modalities such as staining with the vital dye Rose Bengal, determination of tear ferning or measurement of tear film breakup time or tear film osmolarity are used to varying degrees by those investigating the canine tear film but in clinical practice the Schirmer tear test remains the key diagnostic test. Understanding the pathogenesis and treatment of canine keratoconjunctivitis sicca is important for the animals thus affected, but also in the manner it provides a useful spontaneous model for dry eye in human patients. Other models include rodents with inherited predisposition to dry eye and those in which a continual airflow dries the ocular surface, but the spontaneous canine model has the advantage of an eye much more similar in size to the human eye than is the mouse or rat globe and an outbred species living in the same environment as the human patients.
